Characteristic:
Light weight
Clean and environmental friendly
Good cushion performance
Excellent low temperature resistance
Good chemical resistance
Reusable
Outstanding resilience
Basic Physical Properties
Test Item
|
Test Method
|
Unit
|
PEBA07
|
PEBA10
|
Density
|
ISO 845:2006
|
g/cm³
|
0.07-0.08
|
0.09-0.11
|
Hardness
|
SATRA TM 205-16
|
Shore C
|
35
|
40
|
Test results of mechanical properties
Test Item
|
Test Method
|
Unit
|
PEBA07
|
PEBA10
|
Tensile Strength
|
ISO 1798:2008
|
MPa
|
1.8
|
2.6
|
Elongation at Break
|
ISO 1798:2008
|
%
|
160
|
120
|
Young’s Modulus
|
ISO 1798:2008
|
MPa
|
/
|
3.6
|
Shrinkage
|
ASTM D1148
|
%
|
/
|
0.8
|
Resiliency
|
ASTM D1148
|
%
|
/
|
65
|
Method A Tear Trouser Test
|
ISO 8067:2008
|
N/cm
|
15
|
18
|
Method B Tear Angle Test
|
ISO 8067:2008
|
N/cm
|
55
|
60
|
Ball Resilience
|
ASTM D3574
|
%
|
73
|
73
|
M-PEBA 07
Density: 0.07-0.08 g/cm³
Hardness: 35 HC
Tensile Strength: 1.8MPa
Applications: Midsole,insole
M-PEBA 10
Density: 0.09-0.11 g/cm³
Hardness: 40 HC
Tensile Strength: 2.6MPa
Applications: Midsole,insole
